VMCH Lamination Coating Machine

About VMCH Lamination Coating Machine

ACCUWEB has developed special type VMCH Coating Machine

Technical Specification Of V.M.C.H Coating

• Working Width : 1250 mm
• V.M.C.H coating on Aluminum foil, and to Apply a thin coating of shellac on reverse foil surface in a single operation.
• Dry lamination of two webs
• Speed : Solvent base adhesive speed 100 mtr/minute
• VMCH Coating for foil speed 4 Gsm 40 to 80 mtr/minute and 6 Gsm 40 to 50 mtr/minute
• Water base adhesive coating speed 35 mtr/minute
• 1) Shellac coating : Gravure method Separate three air blower for shellac wash unit Air nozzles distribute uniform not air across the wash width and are placed against idle rollers for proper web support Air volumes can be controlled by manual dampers at each station
  2) V.M.C.H coating : Three roll coating system / Gravure method
• Pneumatic application for pressure roller, Doctor blade, Drying hood and Nip unit. Screw type adjustable roller at different points
